Bucket Elevators
Robust and of high servicability: Our bucket elevators are second-to-none.

Our bucket elevators come with a choice of normal steel version with painted or galvanised surface, and a stainless steel version. The elevator foot is fitted with a belt tensioner. The actual belt runs in a caged pulley in the foot in order to avoid caking which could otherwise impair correct operation.
With the selection of bucket type, number of buckets per meter and by defining the belt speed Künzel experts can optimise the operating parameters for the individual application and the required capacity.
Type | Belt speed m/s | Capacity m³/h | Malt conveying capacity t/h | Motor output kW | Height m |
---|---|---|---|---|---|
E 315/132 | 2 – 2,8 | 12 – 30 | 6,5 – 15 | 0,75 – 2,2 | 4 – 55 |
E 400/200 | 2 – 2,8 | 26 – 50 | 14 – 27 | 0,75 – 3,7 | 5 – 55 |
E 500/250 | 2 – 2,8 | 39 – 94 | 21 – 51 | 1,1 – 5,5 | 5 – 55 |
E 630/315 | 2 – 2,8 | 55 – 157 | 30 – 85 | 3,0 – 11,5 | 5 – 55 |
E 800/400 | 2 – 2,8 | 150 – 200 | 80 – 100 | 9,0 – 12,0 | 5 – 55 |
Künzel bucket elevators are particularly safe to operate and are fitted with the following monitoring and safety elements:
All Künzel components are able to meet the requirements of explosion protection according to ATEX, NFPA or other country specific guidelines.
